HPH Series 160/200 kVA

Three Phase UPS

Power Reliability with the Best Total Cost of Ownership

160KVA Order number: GES164HH330035 NEW HPH 160kVA 3 Phase in, 3 Phase out, 220/380V 50HZ, without battery
200KVA Order number: GES204HH330035 NEW HPH 200kVA 3 Phase in, 3 Phase out, 220/380V 50HZ, without batteryDownload leaflet

Download PDFpdf

Email for enquiry



Description

Highly reliable and efficient backup power for medium enterprise operations

The brand-new Ultron HPH series 160-200kVA is a true online double-conversion UPS offering the best-in-class combination of power performance and efficiency for medium data centers, pan-IT, and other mission critical applications. Thanks to Delta’s R&D expertise and excellent engineering capabilities, the Ultron HPH features up to 96.5% AC-AC efficiency, low iTHD < 3%, and high input power factor > 0.99 resulting in significant total cost of ownership (TCO) savings.

Highlights of the highly reliable Ultron HPH series UPS design include key component redundancy and proactive battery health detection. With its combination of superior availability and power performance, the Ultron HPH 160-200kVA is the top choice for power protection of sustainable medium business operations.



Features

Model HPH-160K / HPH-200K
Power Rating
HPH-160K : 160kVA* / 150kW
HPH-200K : 200kVA / 200kW
Input
Nominal Voltage
220/380 Vac, 230/400 Vac , 240/415 Vac (3-phase, 4-wire + G)
Voltage Range
176 ~ 276Vac (full load)
Current Harmonic Distortion ≦ 3% **
Frequency 40 ~ 70 Hz
Output
Voltage 220/380 Vac, 230/400 Vac , 240/415 Vac (3-phase, 4-wire + G)
Voltage Harmonic Distortion ≦ 0.5% (linear load)
Frequency 50/60 Hz
Frequency Regulation ±0.05 Hz (battery mode)
Overload Capability
≦ 125% : 10 minutes
≦ 150% : 1 minute
