RowCool 35kW

Category: Uncategorized

Description

As power density increases in modern data centers, traditional precision cooling fails to provide complete cooling for the following situations:

The Delta InfraSuite Precision Cooling RowCool Series can effectively solve the above.

High Energy Efficiency Ratio (EER) design with best indoor and outdoor unit combinations provide low annual operating costs
Built-in compressor with inverter capable of variable speeds at different loadings for cost-saving operations
Continuously variable speed EC indoor and outdoor fan design for energy savings
High cooling capacity within compact footprint helps users save on data center space and procurement investment

Modular rack design readily expandable as required to enable quick configuration and eliminate hot spots
Supporting group control and use as backup for load variations in peak and off-peak periods
Optional reheater and humidifier accessories for more precise temperature and humidity control
Built-in high / low pressure switch, compressor temperature sensor, air flow sensor, and more that notify users early and reduce maintain time
Repair from front/rear and a modular components design reduces checking and maintenance time
Low speed to keep compressor running at low loading and avoid frequent stop/start to ensure compressor life

Horizontal air flow suitable for data centers without raised floor saves on construction costs
Pipe and power connections suitable for both top and bottom insertion, with flexible configuration as required
Disposable filters with high efficiency (MERV 8), and washable MERV 1 filters are available for purchase to save cost
Remote monitoring through SNMP card providing more comprehensive system protection

Model	HCH6C60 HCH6C60 Humidity Control
Type	Air-Cooled
Max cooling capacity	37.2kW
Max sensible cooling capacity	36.1kW
Max input current	[HCH6C60]: 28.4A [HCH6C60 Humidity Control]: 36.6A
Input power	3N~, 380V, 50/60Hz
Air flow	8340 CMH
Compressor	Inverter-driven scroll compressor
Refrigerant	R410A
Filter	MERV8
Reheater	[HCH6C60]: N/A [HCH6C60 Humidity Control]: 5.4kW
Humidifier	[HCH6C60]: N/A [HCH6C60 Humidity Control]: 3kg/h
