RowCool 70/95 kW

Category: Uncategorized

Description

As the power density increases in modern data centers, traditional precision cooling fails to provide complete cooling for the following situations:

The Delta InfraSuite Precision Cooling RowCool Chilled Water can effectively solve the above problems.

Applications:

Built-in dual input for better power reliability
Panel made of cold-rolled steel plate and coated with surface electrostatic spraying of epoxy is highly resistant to rust
Built-in leakage detector capable of leak display and alert
Modular rack design readily expandable by load to enable quick configuration of new cooling units
Built-in manual dehumidifying for quick and precise dehumidification
Supporting group control and used as backup

Chilled water pipe suitable for both top and bottom insertion, with top and bottom input power wiring, providing flexible configuration as required
Wheels on bottom for easy moving to locations that need cooling
Disposable filter with high efficiency (MERV 8 ASHRAE 52.2)
Remote monitoring can be carried out through SNMP card, providing more comprehensive system protection
Optional reheater and humidifier accessories for more precise temperature and humidity control

To comply with the high power density of racks, the RowCool series cooling capacity can increase up to 120kW (HCH1CD0) without changing footprint

– for RowCool 95kW

When Applied to the high temperature settings of inlet water, outdoor units save on power consumption by up to 15~20% when the chiller water temperature increases from 5°C to 12°C
Continuously variable speed fan design for energy saving
Cooling system capable of variable flow control for energy saving
Built-in vortex wafer flow meter capable of monitoring chilled water flow that renders easy display of system status

RowCool 70kW
Model	HCH1CB0 HCH1CB0 with reheater/humidifier
Capacity
Maximum cooling capacity *1 Sensible cooling capacity	70 kW 69.3 kW
Power
Input power Maximum input power Maximum current	3Φ4 W+G/50,60 Hz/ 380 V HCH1CB0: 3 kW HCH1CB0 with reheater/humidifier: 14 kW HCH1CB0: 5 AMP HCH1CB0 with reheater/humidifier: 22 AMP
